BKTT 25a cupcake Mini 2 boasting 5a and slimline design! Now with colorful LED color options

please note these are not plug- And play! These do require tuning and learning of the settings.

welcome to the cupcake Mini 2, It’s the same awesome hardware and firmware from the amazing escape 32 organization… But now on a smaller design And still boasting that 5A Adjustable BEC And now color LED options To add that aesthetic to your truck. To simply click on the LED light you want and let it fill up that cab.

Features:
• Cross-platform Wifi access on all devices
• Simple "Plug n' Play" access thru Wifi-Link
• Integrated Wifi-Link controllable BEC voltage
• PH2.0, JST, & XT30 Battery Plug Options
• Hi-performance ESCape32 Firmware
• Hard-mounted PH2.0 3pin Motor plug
• Custom programmable startup tones
• Future-proof Wifi-Link programmer compatible (sold separately)
• Sensorless brushless & brushed modes
• Advanced brushed mode settings
• Sinusoidal brushless mode for slow speed crawler control
• Programmable Low-Voltage Cutoff & Drag Brake
• Integrated Voltage Sensor
• Telemetry (KISS, KISS auto, iBUS, S.Port, CRSF)
• Anti-arching and parasitic voltage spike protection
  **TVS Diode offers protection against:
   1) While plugging in your battery (arching during connection)
   2) Rapid motor braking when damped mode is enabled

Specs:
• MCU: STM32G071
• Firmware: ESCape32 Rev. 14.5 "ESCAPE5"
• Voltage: 2-6S (5-6S use external 470uF cap)
• Current: 25A (50amp Burst)
• Sensors: voltage
• BEC: 5.5/6.5/7.4/8.4V 5A continuous
• Size: 30mm x 12mm x 6mm

We give a 30 day hardware #Warranty only as the firmware is open source and cannot be warranted. The item needs to come back to us for troubleshooting any inspection first before we replace or give a #Warranty.
